SKF U 312 Thrust Ball Bearing Specifications
-
Banded:No
-
Bore 1:3.346 Inch / 85 Millimeter
-
Bore 2:3.346 Inch / 85 Millimeter
-
Brand:SKF
-
Category:Thrust Ball Bearing
-
Component Description:Aligning Washer Only
-
EAN:7316570294361
-
Harmonized Tariff Code:8482.99.25.80
-
Height:0.453 Inch / 11.5 Millimeter
-
Inch - Metric:Metric
-
Keyword String:Aligning Thrust
-
Long Description:85MM Bore 1; 85MM Bore 2; 115MM Outside Diameter; 11.5MM Height; Single Direction; Not Banded
-
Manufacturer Item Number:U 312
-
Manufacturer Name:SKF
-
Manufacturer URL:
-
Noun:Washer
-
Optional Components:Order 53312 Bearing and Raceway Separately
-
Other Features:Sphered Housing
-
Outside Diameter:4.528 Inch / 115 Millimeter
-
Overall Height with Aligning Washer:0 Inch / 0 Millimeter
-
Rolling Element:None
-
Single or Double Direction:Single Direction
-
Thrust Bearing:Yes
-
UNSPSC:31171500
-
Weight / Kilogram:0.343
-
Weight / LBS:0.756
