SKF SYF 40 FM Pillow Block Bearing

Specs

Actual Bolt Center to Center:

3.5 Inch / 90Millimeter

Base to Center Height:

1.937 Inch / 49.2 Millimeter

Bolt Spacing Maximum:

0 Inch / 0Millimeter

Bolt Spacing Minimum:

0 Inch / 0Millimeter

Bore:

1.575 Inch / 40 Millimeter

Brand:

SKF

Category:

Pillow Block Bearings

EAN:

7316570416299

Expansion / Non-expansion:

Non-expansion

Harmonized Tariff Code:

8483.20.40.40

Housing Configuration:

1 Piece Solid

Housing Material:

Cast Iron

Housing Style:

2 Bolt Tap Base Pillow Block

Inch - Metric:

Metric

Insert Part Number:

YET 208

Keyword String:

Pillow Block

Length Thru Bore:

1.72 Inch / 43.7 Millimeter

Long Description:

2 Bolt Tap Base Pillow Block; 40MM Bore; 49.2MM Base to Center Height; Eccentric Collar Mount; Ball Bearing; Relubricatable; Cast Iron; M Seal; Non-expansion

Manufacturer Item Number:

SYF 40 FM

Manufacturer Name:

SKF

Manufacturer URL:

http://www.skf.com"

Mounting Bolts:

12 Millimeter

Mounting Method:

Eccentric Collar

Nominal Bolt Center to Center:

3.5 Inch / 90 Millimeter

Noun:

Bearing

Number of Mounting Holes:

2

Other Features:

Single Row / Narrow Inner Race / Short Base / Y Bearing

Relubricatable:

Yes

Rolling Element:

Ball Bearing

Seals:

M Seal

UNSPSC:

31171511

Weight / Kilogram:

1.747

Weight / LBS:

3.42
