SKF BT 7107 Ball Transfer Unit

  • SKUQV97QX
  • Brand
  • Manufacturer Part #BT 7107
  • Available to Order

    Expected to Arrive ***


 Images may not be exact. Please refer to Part # and Description.

$91.76

SKF BT 7107 Ball Transfer Unit Specifications

  • Ball Outside Diameter:
    0.5 Inch / 12.7 Millimeter
  • Base to Ball Height:
    0.772 Inch / 19.6 Millimeter
  • Brand:
    SKF
  • Category:
    Ball Transfer Unit
  • EAN:
    7316578001589
  • Fitting Type:
    Stud / Spring Loaded
  • Flange Size if applicable:
    Not Applicable
  • Housing Diameter:
    0.811 Inch / 20.6 Millimeter
  • Housing Height:
    0.634 Inch / 16.1 Millimeter
  • Inch - Metric:
    Metric
  • Long Description:
    Ball Transfer Unit; Stud|Spring Loaded; 12.7MM Ball Diameter; 19.6MM Base to Ball Height; 20.6MM Housing Diameter; 16.1MM Housing Height
  • Manufacturer Name:
    SKF
  • Other Features:
    High Capacity / Optional Drain Hole and Grease Point / Shock Loading Protection
  • Overall Height:
    1.85 Inch / 47 Millimeter
  • Product Name:
    Ball Transfer Unit
  • Stud Height if applicable:
    1.079 Inch / 27.4 Millimeter
  • Stud Thread Length:
    1.079 Inch / 27.4 Millimeter
  • Stud Thread Size:
    M8
  • UNSPSC:
    24101700
  • Weight / Kilogram:
    0.067
