RBC Bearing B36L

  • SKUUT54OX
  • Brand
  • Manufacturer Part #B36L
  • Available to Order

    Expected to Arrive ***


 Images may not be exact. Please refer to Part # and Description.

$172.44

RBC Bearing B36L Specifications

  • Ball Material:
    Ball Bearing Steel, Hardened & Ground
  • Dynamic Load Rating:
    47700 lbf
  • EAN or UPC:
    637400001643
  • Enclosure:
    Unsealed
  • I.D.:
    2 1/4 in
  • Inner Ring Width:
    1.969 in
  • Insert Material:
    N/A
  • O.D.:
    3 9/16 in
  • Outer Race Material:
    Bearing Quality Steel
  • Outer Ring Width:
    1 11/16 in
  • Radial Load Rating [MAX]:
    191000 lbf
  • Self-Lubricating:
    No
  • Spherical Diameter:
    3.235 in
  • Static Load Rating [MAX]:
    191000 lbf
  • Thrust Load Rating [MAX]:
    42000 lbf
  • Tilting Angle [MAX]:
    12 degrees
  • Weight:
    2.92 LB
