NSK

NSK Bearing SUCSP204-12

MFG Part #
SUCSP204-12
SKU#
LU30NY

Specifications

Base to Bore Centerline1.3125 in
Base Width1.5000 in
Bolt Center-to-Center Length3.7400 in
Bolt Size0.4375 in
Bore Diameter0.7500 in
See all product specifications

Need Some Help?

Get real service from real people, that know the products!

Monday - Friday

5:00am - 5:00pm PST

Specs

Base to Bore Centerline:
1.3125 in
Base Width:
1.5000 in
Bolt Center-to-Center Length:
3.7400 in
Bolt Size:
0.4375 in
Bore Diameter:
0.7500 in
Bore Type:
Round
Duty Type:
Standard Duty
End Type:
Open
Expansion Type:
Non-Expansion Bearing (Fixed)
Housing Material:
304 Stainless Steel
Insert Bearing Type:
Ball Bearing
Locking Device:
Set Screw
Lubricant:
Mobile FM222 USDA H1
Lubrication Type:
Lubrication Fitting
Manufacturer UPC Number:
29176873492
Mounting:
Two-Bolt Base
Overall Height:
2.5600 in
Overall Length:
4.9600 in
Replacement Bearing:
SUC204-12
Seal Material:
AISI 302 Stainless Steel, Rubber
Weight:
0.8 kg

Description

Since 1916 NSK has manufactured Bearings and Power Transmission components across the globe. From Automotive to Wind Energy – NSK is developing and manufacturing products for a wide variety of applications in key industrial sectors, all over the world. Along with quality, NSK manufacturers more ball bearings than any other manufacturer.
$172.91
