KOYO J-2816

  • SKUDY37TN
  • Brand
  • Manufacturer Part #J-2816
  • Available to Order

    Expected to Arrive ***


 Images may not be exact. Please refer to Part # and Description.

$29.59

KOYO J-2816 Specifications

  • Bearing Design:
    Outer Ring & Roller Assembly
  • Bore Type:
    Round Bore, Inch Type
  • Cage Material:
    Steel
  • Capacity:
    Standard Capacity
  • EAN or UPC:
    605790195525
  • Enclosure:
    Open
  • End Type:
    Open End
  • Housing Bore [MAX]:
    2.1255 in
  • Housing Bore [MIN]:
    2.1245 in
  • I.D.:
    1 3/4 in
  • Limiting Speed - Oil:
    7300 rpm
  • O.D.:
    2 1/8 in
  • Oil Hole:
    w/o Oil Hole
  • Origin:
    Needle Radial
  • Precision Ground:
    No
  • Radial Internal Clearance Specification:
    N/A
  • Radial Internal Clearance:
    N/A
  • Self Aligning:
    No
  • Tolerance:
    Iso Class 0 (RBEC 1)
  • Weight:
    0.222 LB
  • Width:
    1 in
  • Working Load:
    8690 lbf
