KOYO CRSBC-8

  • SKUEL33JD
  • Brand
  • Manufacturer Part #CRSBC-8
  • Available to Order

    Expected to Arrive ***


 Images may not be exact. Please refer to Part # and Description.

$58.93

KOYO CRSBC-8 Specifications

  • Bearing Type:
    Needle Bearing
  • Clamp Torque:
    8 lbf
  • Clamping Dia.:
    0.2969 in
  • Dynamic Load Rating:
    958 lbf
  • EAN or UPC:
    605790198472
  • Enclosure:
    Sealed
  • End Type:
    Hex Hole
  • Fillet Radius:
    0.01 in
  • Inch/Metric:
    Inch
  • Limiting Speed:
    7500 rpm
  • Material:
    Steel
  • Mounting Overhang:
    0.41 in
  • Overall Length:
    0.87525 in
  • Package Quantity:
    1.0 Piece
  • Roller Dia.:
    1/2 in
  • Roller Type:
    Crowned
  • Roller Width:
    0.344 in
  • Stud Dia.:
    0.19 in
  • Stud Length:
    1/2 in
  • Stud Type:
    Standard
  • Thread Length:
    1/4 in
  • Thread Pitch:
    N/A
  • Thread Size:
    #10
  • Thread Type:
    UNF
  • Threads per Inch:
    32
  • Weight:
    0.042 LB
  • Working Load:
    306 lbf
