KOYO

KOYO 60262RSC3

MFG Part #
60262RSC3
SKU#
RX30BT

Specifications

Ball MaterialSteel
Bearing TypeRadial
Bore TypeRound Bore
Cage MaterialSteel
Cage TypeMetal
See all product specifications

Need Some Help?

Get real service from real people, that know the products!

Monday - Friday

5:00am - 5:00pm PST

Specs

Ball Material:
Steel
Bearing Type:
Radial
Bore Type:
Round Bore
Cage Material:
Steel
Cage Type:
Metal
Capacity:
Standard Capacity
Contact Angle:
0°
Dynamic Load Rating:
22705 lbf
EAN or UPC:
605790371035
Enclosure:
Double Sealed
Fillet Radius:
2 mm
I.D.:
130 mm
icNumber:
7701168
Inch/Metric:
Metric Bore
Inner Ring Width:
33 mm
Limiting Speed - Grease:
1900 rpm
Limiting Speed - Oil:
3800 rpm
Locking Device:
No Locking Device
Lubricant:
Mul-Temp SRL
Material:
Steel
No. in Set:
Single Bearing
O.D. Type:
Straight
O.D.:
200 mm
Origin:
Single Row Radial
Outer Ring Width:
33 mm
Precision Level:
Standard (ABEC 1)
Precision:
Standard
Preload Level:
None
Radial Internal Clearance Specification:
Greater Than Normal Clearance
Radial Internal Clearance:
C3
Rows of Balls:
Single
Seal Material:
Rubber
Seal Type:
Contact Seals
Snap Ring:
No Snap Ring
Static Load Rating [MAX]:
23829 lbf
Temperature Range [MAX]:
212 ?F
Temperature Range [MIN]:
-22 ?F
Weight:
7.476 LB
Width:
33 mm
$989.62
