KOYO 29416RNFY Specifications
-
Bearing Type:Thrust
-
Bore Type:Round Bore
-
Cage Material:Brass/Bronze
-
Dynamic Load Rating:113529 lbf
-
EAN or UPC:605790018510
-
Enclosure:Unsealed
-
Fillet Radius:2.1 mm
-
I.D.:80 mm
-
Limiting Speed - Oil:2000 rpm
-
O.D.:170 mm
-
Origin:Spherical Thrust
-
Radial Internal Clearance Specification:Normal Clearance
-
Radial Internal Clearance:Normal
-
Ring Modification:None
-
Static Load Rating [MAX]:332717 lbf
-
Tolerance:Iso Class 0 (Equiv. to RBEC 1)
-
Weight:11.4 LB
-
Width:54 mm
