Dodge 481996 Pulleys - Synchronous

Specs

Belt Pitch:

8 Millimeter

Belt Style:

8M-62

Belt Width:

2.441 Inch / 62 Millimeter

Bore:

0 Inch / 0 Millimeter

Brand:

DODGE

Bushing Bore Range:

1/2 To 1-11/16 Inch / 14 To 42 Millimeter

Bushing Size:

1610

Category:

Pulleys - Synchronous

EAN:

782476698591

Face Width:

2.625 Inch / 66.675 Millimeter

Flange Outside Diameter:

3.81 Inch / 96.774 Millimeter

Flanges:

Yes

Harmonized Tariff Code:

8483.50.90.80

Inch - Metric:

Metric

Keyway Yes/No:

Yes

Keyword String:

Synchronous

Long Description:

Pulley, Synchronous; 62MM Belt Width; 8 Millimeter Belt Pitch; 8M-62 Belt Style; 34 Teeth; 66.675MM Face Width; Bushed; 96.774MM Flange OD; 84.988MM Outside Diameter; 86.58MM Pitch Diameter; Keyway; 1610 Bushing; No Minimum Plain Bore

Manufacturer Name:

ABB MOTORS AND MECHANICAL INC

Manufacturer URL:

http://www.dodge-pt.com"

Minimum Plain Bore:

No

Mounting Method:

Bushed

Noun:

Pulley

Number of Teeth:

34

Other Features:

Poly Chain GT2 Belt Style / Taper Lock Bushing / Solid Style

Outside Diameter:

3.346 Inch / 84.988 Millimeter

Pitch Diameter:

3.409 Inch / 86.58 Millimeter

UNSPSC:

26111812

Weight / LBS:

5

Weight / US pound:

0.01
