Dodge 481893 Pulleys - Synchronous

Specs

Belt Pitch:

8 Millimeter

Belt Style:

8M-12

Belt Width:

0.472 Inch / 12 Millimeter

Bore:

0 Inch / 0 Millimeter

Brand:

DODGE

Bushing Bore Range:

1/2 To 2-1/8 Inch / 14 To 50 Millimeter

Bushing Size:

2012

Category:

Pulleys - Synchronous

EAN:

782476698072

Face Width:

0.57 Inch / 14.478 Millimeter

Flange Outside Diameter:

4.91 Inch / 124.714 Millimeter

Flanges:

Yes

Harmonized Tariff Code:

8483.50.90.80

Inch - Metric:

Metric

Keyway Yes/No:

Yes

Keyword String:

Synchronous

Long Description:

Pulley, Synchronous; 12MM Belt Width; 8 Millimeter Belt Pitch; 8M-12 Belt Style; 42 Teeth; 14.478MM Face Width; Bushed; 124.714MM Flange OD; 105.35MM Outside Diameter; 106.959MM Pitch Diameter; Keyway; 2012 Bushing; No Minimum Plain Bore

Manufacturer Name:

ABB MOTORS AND MECHANICAL INC

Manufacturer URL:

http://www.dodge-pt.com"

Minimum Plain Bore:

No

Mounting Method:

Bushed

Noun:

Pulley

Number of Teeth:

42

Other Features:

Poly Chain GT2 Belt Style / Taper Lock Bushing / Solid Style

Outside Diameter:

4.148 Inch / 105.35 Millimeter

Pitch Diameter:

4.211 Inch / 106.959 Millimeter

UNSPSC:

26111812

Weight / LBS:

2.2

Weight / US pound:

0.01
