Dodge 104746 Roller Chain SPROCKET

Specs

Bore:

0 Inch / 0 Millimeter

Brand:

DODGE

Bushing Bore Range:

1/2 To 2-11/16 Inch / 14 To 65 Millimeter

Bushing Size if bushed:

2517

Category:

Roller Chain Sprockets

Chain Pitch:

1 Inch / 25.4 Millimeter

Chain Size:

80

Chain Type:

ANSI Roller Chain

EAN:

782475596317

Hardened Teeth:

No

Harmonized Tariff Code:

8483.90.10.50

Hub Type:

B-Hub One Side

Inch - Metric:

Inch

Keyway Yes/No:

Yes

Keyword String:

Roller Chain

Long Description:

80 Chain; 42 Teeth; 1 Row of Teeth; No Hardened Teeth; 13.944 Outside Dia

Manufacturer Internal Number:

104746

Manufacturer Name:

ABB MOTORS AND MECHANICAL INC

Manufacturer URL:

http://www.dodge-pt.com

Material:

Steel

Max Bore:

0

Minimum Plain Bore:

No

Mounting Method:

Bushed

Noun:

Sprocket

Number of Teeth:

42

Other Features:

Taper Bushing

Outside Diameter:

13.944 Inch / 354.178 Millimeter

Pitch Diameter:

13.382 Inch / 339.903 Millimeter

UNSPSC:

31171901

Weight / Kilogram:

11.4

Weight / LBS:

25.1
